What goes in a SOC dashboard in Metabase?

A SOC dashboard tracks the security operations center as an operation: alert volume by severity and source, triage speed (MTTA and MTTR), false-positive rate, escalations to incidents, and analyst workload. It's the management layer over the SIEM console — the console is where analysts triage; this is where the SOC lead sees whether triage is keeping up. Metabase builds it from SIEM, EDR, and case-management exports, alongside alert quality and incident response trends.

What does a SOC dashboard look like?

Here’s the layout this guide builds. The shift-handover row leads — volume, escalations, acknowledge time, false-positive rate, and the open queue — so an incoming shift reads one line; alert flow and triage follow, tracing alerts from source through the funnel to incidents; quality, workload, and coverage close the page, because those are the levers the SOC lead pulls week to week rather than shift to shift.

Which cards belong on a SOC dashboard?

The eight below cover throughput, speed, quality, and capacity — the four things that decide whether a SOC is coping or silently backing up.

• Alerts by severity per week — volume and mix over the last eight weeks (stacked bar)
• Alerts by source — EDR, email gateway, identity, cloud logs, WAF (row)
• From alert to incident — received, triaged, investigated, escalated (funnel)
• Time to acknowledge and resolve — median MTTA and MTTR per week (combo)
• False-positive rate per week — against the team’s target (line)
• Alerts closed per analyst — workload balance across the team (row)
• Detection coverage by ATT&CK tactic — % of techniques with an active rule (row)
• Escalated incidents — the last 7 days, with source, severity, and assignee (table)

What data does the dashboard need?

• An alerts table — alert_id, source, severity, rule_id, created_at, acknowledged_at, resolved_at, disposition, assignee.
• An escalated_incident_id column (or an incidents table keyed to alerts) so escalations can be counted and joined.
• A detection_rules table with rule status and mapped ATT&CK techniques, for the coverage card.
• Analyst shift or roster data if you want workload normalized per shift rather than raw counts.
• Paging records (e.g., PagerDuty) if off-hours load and paging noise should appear alongside — see the alert quality dashboard for that cut.

How do you build it?

1. Schedule exports from the SIEM/SOAR into your warehouse — hourly for the alerts table, daily for rules — keyed on alert_id so re-syncs upsert cleanly.
2. Enforce dispositions at closure in the source tool; the false-positive card is only as good as the discipline behind that field.
3. Model triage durations once (created → acknowledged → resolved, as minutes), using medians in every card so one weekend alert can’t skew a week.
4. Build the funnel from alert states and the coverage card from the rule-to-technique mapping; both are ordinary grouped queries, not special tooling.
5. Add filters for severity, alert source, and date range; pin the queue and handover cards to the top and subscribe the SOC channel to a start-of-shift snapshot.

Example card SQL

SELECT
date_trunc('week', a.created_at)                       AS week,
COUNT(*)                                               AS alerts,
COUNT(*) FILTER (WHERE a.severity = 'critical')        AS critical,
PERCENTILE_CONT(0.5) WITHIN GROUP (
  ORDER BY EXTRACT(epoch FROM a.acknowledged_at - a.created_at) / 60
)                                                      AS mtta_minutes,
PERCENTILE_CONT(0.5) WITHIN GROUP (
  ORDER BY EXTRACT(epoch FROM a.resolved_at - a.created_at) / 3600
) FILTER (WHERE a.resolved_at IS NOT NULL)             AS mttr_hours,
ROUND(
  100.0 * COUNT(*) FILTER (WHERE a.disposition = 'false_positive')
    / NULLIF(COUNT(*) FILTER (WHERE a.disposition IS NOT NULL), 0), 1
)                                                      AS false_positive_pct,
COUNT(*) FILTER (WHERE a.escalated_incident_id IS NOT NULL)
                                                       AS escalated_to_incident
FROM alerts a
WHERE a.created_at >= now() - interval '8 weeks'
GROUP BY 1
ORDER BY 1;
